3WPZ-3000 Self-Propelled Sprayer

The 3WPZ-3000 Self-Propelled Sprayer is a DUOJIA agricultural spraying machine designed for efficient field crop spraying and precision application. Manufactured by Hefei Duojia Agricultural Technology Co., Ltd., the machine combines four-wheel drive, four-wheel steering, a 3000 L spray tank, a 20 m boom, multiple air curtains, and precision spraying functions.

The sprayer is designed to address application requirements including droplet drift, inaccurate dosage, and low working efficiency. Its configuration supports field spraying for cotton, rice, wheat, corn, soybean, and other crops, as well as cotton topping agent and defoliant applications.

Key Features

• 3000 L tank capacity: Provides a large spray liquid capacity for field spraying operations.
• 20 m boom: The long boom supports wide-area spraying during field operations.
• Four-wheel drive and steering: Four-wheel drive and four-wheel steering provide the documented mobility configuration, while front and rear wheels follow the same track to reduce crop pressing.
• Multiple air curtains: The machine is equipped with multiple air curtains, enabling high-speed precision operation in Level 4 wind according to the supplied product information.
• Precision nozzles: High-precision nozzles provide atomization and fine droplets. The supplied product information states that target-oriented application can save more than 50% of chemicals.
• Precision cotton applications: The machine supports precise dosage application for cotton topping agents and cotton defoliants.
• Optional variable spray control: A variable spray control system is available as an optional configuration for variable-rate application.
• Diaphragm pump system: The sprayer is matched with a 6280 diaphragm pump and has a working pressure range of 0.2–0.5 MPa.

Technical Specifications

Note: 1 mu ≈ 0.0667 ha. Specifications are subject to change without notice. Please confirm final parameters with our sales team before system design.

Applications

The 3WPZ-3000 is documented for the following agricultural spraying applications:

• Field spraying for cotton, rice, wheat, corn, soybean, and other crops
• Cotton topping agent application
• Cotton defoliant application
• Target-oriented spraying
• High-speed precision spraying under moderate wind conditions
• Variable-rate application with the optional variable spray control system

For cotton topping agent application, the supplied product information states that precise dosage can control apical dominance and provide uniform cotton plant growth.

For cotton defoliant application, the machine is designed with no hanging spray nozzles that catch cotton bolls, and the supplied information states that one application can meet defoliation standards.

Why Choose 3WPZ-3000 Self-Propelled Sprayer

• High working efficiency: Working efficiency can reach up to 100 mu/h.
• Target-oriented application: The supplied product information states that target-oriented application can save more than 50% of chemicals.
• Air-curtain spraying: Multiple air curtains support high-speed precision operation in Level 4 wind according to the documented product information.
• Four-wheel drive and steering: The drive and steering configuration provides the documented mobility characteristics.
• Same-track wheel configuration: Front and rear wheels are on the same track to reduce crop pressing.
• Precision dosage application: The machine supports precise dosage application for cotton topping agents and defoliants.
• Variable-rate capability: The variable spray control system is available as an optional configuration.

Ordering Information

When placing an inquiry for the 3WPZ-3000, please specify:

• Model: 3WPZ-3000 Self-Propelled Sprayer
• Variable spray control system: Optional, Yes / No
• Quantity required

Frequently Asked Questions

What type of machine is the 3WPZ-3000?

The 3WPZ-3000 is a Self-Propelled Sprayer with four-wheel drive and four-wheel steering, designed for agricultural field spraying applications.

What is the tank capacity of the 3WPZ-3000?

The sprayer has a 3000 L tank capacity.

What is the boom length of the 3WPZ-3000?

The documented boom length is 20000 mm, equivalent to 20 m.

What is the working efficiency of the 3WPZ-3000?

The working efficiency can reach up to 100 mu/h according to the supplied product information.

Is variable spray control included as standard?

The Variable Spray Control System is optional. When ordering, buyers can specify whether this optional configuration is required.

Contact DUOJIA

Contact DUOJIA for product information and technical confirmation for the 3WPZ-3000 Self-Propelled Sprayer. When making an inquiry, provide the required quantity and whether the optional variable spray control system is required so the configuration can be confirmed.
